Horizontal Rubber Injection Compression Molding Machine
應用範圍/Applications
適用於多邊、多角及其它複雜成品，特別是運動用品、醫療用品、汽車用品、高低壓電力、電子用品等精密性高產品應用。
Suitable for in multilateral , polygonal and other complicated products ,sporting goods, medical supplies , automotive supplies, high and low voltage electricity, electronics and other other high precision applications.
特點Characteristics
一、 雙螺杆入料係統，能將空氣完全排除在外，提升品質優良且沒有入料限製，方便快速換料清洗；
二、高精度德製電子尺設計，能準確的控製與計算射出量之大小；
三、 轉射板特殊的座進、座退功能可使射嘴不死料，清洗容易，質量穩定；
四、日製高科技紅外線安全電眼，具有全自動警告係統及多重安全防護裝置，可清楚掌握機台狀況，確保安全；
五、 采用全比例式油路係統，低噪音並具有自動調整壓力大小比例之功能，精準穩定；
1、Twin-screw feeding systems, air can completely excluded, improve quality and excellent rate of feeding and no limit to facilitate rapid refueling leaning;
2、The high-precision German-made electronic foot design, accurate control and calculation of the size of the injection volume;
3、Turn radio board seat to seat back feature allows the nozzle undead material, easy to clean, stable quality;
4、Japanese-made high-tech infrared safety eye automatic warning system and multiple security guards, clearly Grasp the status of the machine to ensure safety;
5、Full-scale oil system, low noise and automatically adjusts the function of pressure size ratio, accurate and stable;
技術參數/Technical parameters：
| 機型Type | EH-200T | EH-300T | EH-400T |
| 出力Clamping force(TON) | 200 | 300 | 400 |
| 行程Stroke(mm) | 550 | 600 | 600 |
| 台麵Heating plate size(mm) | 510*500 | 600*650 | 650*700 |
| 缸徑Diameter of cylinder(mm) | 350 | 450 | 500 |
| 射出量Injection volume(cc) | 2000 | 3000 | 4000 |
| 馬力Horse power(HP) | 15*1 | 20*1 | 25*1 |
| 開模形式Type of mold opening | 上升下降-出入模-前頂2RT/3RT/4RT | ||
| 單軸電熱Single shaft thermal electricity(KW) | 12.6 | 16 | 25 |
| 總電力Total power(KW) | 28 | 36 | 45 |
| 重量Gross weight(KG) | 6000 | 9000 | 9500 |
| 機台尺寸Machine Size(mm) | 3200*2400*2500 | 3700*2560*2710 | 4000*2800*2850 |
如有參數變更，恕不另行通知。We reserve the right to change any design and specification without ontice.
