應用範圍/Applications:
主要生產欧美大香蕉视频自行車配件、欧美大香蕉视频零錢包、欧美大香蕉视频假肢假腳、欧美大香蕉视频直升機、欧美大香蕉视频運動器等各種欧美大香蕉视频製品、玻璃纖維製品。
It mainly produces carbon fiber bicycle accessories, carbon fiber automobiles parts, carbon fiber wallet, carbon fiber artificial limb, carbon fiber UAV, carbon fiber sportswear and other carbon fiber products, glass fiber products.
特點/Characteristics:
一、可配機械自動開模,方便人員操作;
二、采用比壓比流或伺服油路設計,穩定、節能,上升下降速度可因使用需求調整;
三、具有慢速校模功能,校模更精確、更安全。
1、It can be equipped with mechanical automatic mould opening, which is convenient for workers to operate.
2、Adopting specific pressure specific flow or servo oil circuit design, which is stable and energy-saving;increase in the rate of decline may be due to the use of demand adjustment;
3、 Slow moving speed is available for alignment safer and more accurate.
技術參數/Technical parameters:
型號Type | MH-400 | MH-500 | MH-600 | MH-800 | MH-1100 | MH-1500 |
麵板尺寸Heating plate size (mm) | 400*400 | 500*500 | 600*600 | 800*800 | 1100*1100 | 1500*1500 |
合模力Clamping Force (T) | 50T-200T | 100T-500T | 100T-500T | 100T-500T | 150T-500T | 150T-500T |
行程Stroke (mm) | 250-300 | 250-300 | 250-300 | 250-300 | 250-300 | 250-300 |
功率Power (KW) | 2.2 | 3.75 | 5.5 | 5.5 | 5.5 | 5.5 |
控製係統Control System | PLC+HMI | PLC+HMI | PLC+HMI | PLC+HMI | PLC+HMI | PLC+HMI |
工位Workstation (QTY) | 1-3站可定製 | 單站 | ||||
備注Remarks | 麵板尺寸可定做 |
*如有參數變更,恕不另行通知。We reserve the right to change any design and specification without ontice.
